The EZ CUBE even ballast weighs 350lbs and is 100% steel.

Product Spotlight: 12" x 12" x 12" EZ CUBE

The EZ CUBE is the perfect mid-range solution in the EZ BLOCK ballast lineup. Designed as a compact, cubic version of our original flagship block, it offers substantial ballast weight while maintaining an incredibly small footprint. It is a critical component for professionals who need a modular, engineered system that remains "ballroom friendly" and easy to transport.

Engineering & Versatility

  • High-Density Steel: Just like its larger counterpart, the EZ CUBE is 100% steel. This allows it to achieve its 350lb weight in a fraction of the space required by concrete, ensuring it won't crack or deteriorate.

  • Standard 12" Box Truss Integration: The CUBE is specifically engineered for a direct, hard-connection to 12" x 12" aluminum box truss. The top and bottom plates feature the precision bolt patterns needed for a secure, structural base.

  • Adaptive Rigging: It is fully compatible with the EZ HUG system for rigid connections and can support telescoping height adjustments and 360° rotation for signage or lighting structures.

  • Leveling & Support: The design allows for the addition of a standard screwjack in the bottom for leveling on uneven floors or a pipe in the top for supporting specialized structures.

  • Logistical Efficiency: The EZ CUBE is designed for "tilt-and-roll" mobility. Its compact 12" profile means it can be easily moved through standard doorways and passenger elevators by one person with a standard hand dolly.

Close-up of a gray metallic device with a circular hole and black clips on top, with a logo or number '4S' on the surface.

Detailed Specifications

  • Dimensions: 12" x 12" x 12"

  • Weight: 350 lbs

  • Material: Constructed from high-quality ASTM A36 Steel


A metallic machine with a boxy shape, featuring a large circular hole on top and four slots around the hole, with the logo or text 'W5' visible on the top surface.

DOWNLOADS


VectorWorks files of the EZ BLOCK convention ballast are available for download

EZ CUBE 12” x 12” x 12”

VectorWorks Library DOWNLOAD v2025

EZ CUBE 12” x 12” x 12”

VectorWorks Library DOWNLOAD v2026

AutoCAD drawing files of the EZ BLOCK are available for designers to download

EZ CUBE 12” x 12” x 12”

DWG Library DOWNLOAD

STP files of the entire EZ BLOCK product line are available for download for your design needs

EZ CUBE 12” x 12” x 12”

STEP Library DOWNLOAD

Black silhouette of a bird perched on a branch with leaves against a white background.

EZ CUBE ONE SHEET

PDF DOWNLOAD
